Manage battery charging on off-grid PV systems with confidence. CP-B50 is a PWM controller with LCD supporting 12/24/48V battery banks and up to 50A charge current. It features 3-stage PWM charging, real-time charge/discharge current readout and configurable load working modes.
Highlights
-
3-stage PWM charging to extend battery life
-
Auto battery voltage: 12V / 24V / 48V
-
Rated current: 50A
-
LCD display for battery status and currents
-
Configurable load modes (manual / dusk-to-dawn / timer, depending on setup)
-
Multiple electronic protections (overcharge/over-discharge, overload, short-circuit, reverse polarity*)
-
Dedicated PV / BATTERY / LOAD terminals
Technical specs (label)
-
Model: CP-B50 (PWM Solar Charge Controller)
-
Supported battery voltage: 12V / 24V / 48V
-
Rated current: 50A
-
Max PV input voltage: 100V
-
Max PV input power: 650 W (12V), 1300 W (24V), 2600 W (48V)
-
Display: LCD
-
EAN (box): 6199478035367
-
Importer: MEIQ-IT – Via Brecce a S Erasmo 165 (IT)
* Protections listed as “overall effective protection function” on packaging; specific thresholds depend on configuration.
In the box
