Elegant and compact
To give you more space, this multifunction
printer features a compact design. It fits easily into any home office or small
business thanks to its elegant and refined design.
Easy to use
Streamline
tasks with duplex printing, a 150-sheet front-loading paper tray and a 30-page ADF
for scanning, copying and faxing multi-page batches. Navigation is simple with the
easy-to-use interface and large LCD touchscreen.
Minimize expenses
Epson’s four-colour 503 “Pimento” inks deliver reliable,
bright and sharp prints with minimal outlay. Plus, they reduce printing costs with
affordable, individual inks in standard and XL cartridges.
Flexible wireless
solutions
Print from anywhere with Wi-Fi connectivity, or use Wi-Fi Direct
to print from compatible wireless devices without the need for a Wi-Fi network.
Plus, with the Epson Smart Panel app, you can print documents, monitor processes,
and troubleshoot issues 1 , all from your device.
Technical Specifications
Technology
-Printing method: 4 color inkjet printer
-Injector
configuration: 400 black injectors, 128 injectors per color
-Maximum drop
size: 3.3 pl, With variable-size ink droplet technology
-Ink technology: Pigment
black and Dye colour Inks
-Category: Home Office, Office Desktop
-Multifunction:
Print, Scan, Copy, Fax
General
-energy consumption: 12 watt (standalone copying,
ISO/IEC 24712 standard), 1 watt (sleep mode), 5.4 watt Ready, 0.2 watt (off)
-Supply
voltage: AC 100V - 240V, 50Hz - 60Hz
-Product Dimensions: 375 x 347 x 231
mm (width x depth x height)
-Weight: 6.4 kg
-Noise level: 5.2 B (A)
according to ISO 7779 pattern with Epson Premium Glossy Photo Paper / Photo RPM
Mode - 39 dB (A) according to ISO 9226
-Supported operating systems: Mac
OS 10.9.x, Windows 10, Windows 11, Windows 7, Windows 8, Windows Server 2003,
Windows Server 2008 R2, Windows Server 2012 (64-bit), Windows Server 2012 R2,
Windows Server 2016, Windows Vista, Windows XP Professional x64 Edition SP2 or
later, Windows XP SP3 or later (32-bit), macOS 11 or later
-Included Software:
Epson Event Manager, Epson Fax Utility, Epson Photo+, Epson ScanSmart
Impression
-Print speed ISO/IEC 24734: 14 pages/minute Monochrome,
7.5 pages/minute Color
ISO/IEC Duplex Print Speed: 6.5 A4 pages/min. Monochrome,
4.5 A4 pages/min. Color
Print speed: 33 pages/minute Monochrome (Plain Paper
75 g/m²), 20 pages/minute Color (Plain Paper 75 g/m²)
Print resolution:
4,800 x 1,200 dpi
Work cycle: 3,000 pages per month
Colors: Black,
Cyan, Yellow, Magenta
Scanning
-Single-sided scanning speed (A4 black): 200 dpi 200
dpi (with ADF); , 5 ipm with scanning from automatic document feeder (ADF)
-Single-sided
scanning speed (A4 colour): 200 dpi 200 dpi (with ADF); , 5 ipm with scanning
from automatic document feeder (ADF)
-Scan resolution: 1,200 dpi x 2,400
dpi (horizontal × vertical)
-Maximum scan size: 216 mm x 297 mm
-Scanner
Type: Contact Image Sensor (CIS)
Fax
-Fax type: Possibility of sending faxes directly in color
or black and white
-Fax transmission speed: up to 33.6 kbps / Approx. 3
s per page
-Error correction mode: CCITU/ITU Group3 fax with error correction
mode
-Fax speed dial numbers (max.): 100 names and numbers
-Page memory:
up to 100 pages (ITU-T diagram No. 1)
-Fax functions: Fax via PC, Auto Dial,
Speed ??Dial, Address Book, Fax Broadcast, Polling Reception
Handling paper and substrates
-Paper formats: A4 (21.0x29.7
cm), A5 (14.8x21.0 cm), A6 (10.5x14.8 cm), B5, B6, C6 (envelope), DL (envelope),
No. 10 (envelope), Letter, 10 x 15 cm, 13 x 18 cm, 16:9, Custom, C4 (envelope)
-Automatic document feeder: 30 pages
-Proper paper weight: 64 g/m²
- 300 g/m²
-Duplex: Yes (A4 plain paper)
-Paper Tray Capacity: 150
Standard Sheets, 20 Photo Sheets
-Number of paper trays: 1
