LG 75XS4P-B.AEU Signage Display Digital signage flat panel 190.5 cm (75") LED 4000 cd/m² UHD+ Black WebOS 24/7

Attract Passing Customers with a Bright Display Presented Through a Window

World’s First UL Verification for Display Anti-Discoloration Characteristics
By focusing on the pain points of our customers, we obtained the world’s first UL Verification for Display Anti-Discoloration Characteristics. Our new technology helps prevent ‘screen-yellowing’, while safeguarding display quality and performance stability.

Window-facing Display
LG offers advanced technical solutions for cost-effective operations. The XS4P can maintain an astonishing brightness of 4,000 nits, yet has lower power consumption compared to RGB panels at the same brightness level.

Brightness Beyond the Window
A window-facing display requires higher nits, as it is exposed to direct sunlight through a window. The XS4P is designed especially for window-facing environments, providing brilliant brightness. Vibrant and dynamic content displayed through the window will attract customers to your business, despite the viewers wearing polarized sunglasses.

High-performance with webOS 6.0
Quad Core SoC (System-on-Chip) can execute several tasks at the same time without a separate media player. In addition, webOS 6.0 platform enhances not only user convenience with intuitive UI but also web-app integration with updated Node JS / Chromium version.

Remotely Managed, Real-time Mastery (Content Manager)
A significant advantage of window-facing displays over temporary displays is their ability to effortlessly manage frequently changing promotional content and pricing information. LG’s web-based content solution is intuitive and user-friendly, providing users with complete access to current and historical data anytime, anywhere, through their mobile devices. This allows users to monitor, adjust, and control the unit remotely in real-time.

Wide Range of Operating Temperature
The XS4P can be used under a wide range of operating temperature from 0℃ to 40℃.

Conformal Coating
The conformal coating with dust protection shields the circuit and power boards from dust, metal particles, moisture, and other contaminants, providing solid durability and long-term reliability.

Upgraded Quite Mode
The XS4P addresses concerns about display noise. It features an Upgraded Quiet Mode that operates at 2,500 nits with minimal fan noise.

Professional Content Partners
Pairing the XS4P Series with LG SW solutions would enhance its utilization.

Convenient Installation with Calculated Precision
The XS4P is equipped with a Leveler Tool that shows users the tilt of the device, allowing for precise display installation. Additionally, the Horizontal Sensor Tool assists users in verifying the correct installation direction. The XS4P even provides warning messages for proper installation if it is installed incorrectly.

LG 75XS4P-B.AEU. Product design: Digital signage flat panel. Display diagonal: 190.5 cm (75"), Display technology: LED, Display resolution: 3840 x 2160 pixels, Display brightness: 4000 cd/m², HD type: UHD+. Operating hours (hours/days): 24/7. Operating system installed: WebOS. Product colour: Black

Display
Display diagonal	190.5 cm (75")
Display technology	LED
LED backlight	Yes
LED backlighting type	Direct-LED
Display resolution	3840 x 2160 pixels
Display brightness	4000 cd/m²
HD type	UHD+
Touchscreen	No
Native aspect ratio	16:9
Response time	8 ms
Contrast ratio (typical)	1200:1
Contrast ratio (dynamic)	500000:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	1.07 billion colours
Panel life	50000 h
Haze rate	3%
Ports & interfaces
HDMI ports quantity	2
HDMI input ports quantity	2
DVI-D ports quantity	1
DisplayPorts quantity	2
DisplayPorts in	1
DisplayPorts out	1
USB port	Yes
USB ports quantity	1
USB version	2.0
USB connector type	USB Type-A
Ethernet LAN (RJ-45) ports	1
Audio (L/R) out	1
Number of speaker outputs	1
RS-232C	Yes
Infrared data port	Yes
Remote (IR) input	1
Remote (IR) output	1
Audio
Built-in speaker(s)	Yes
RMS rated power	20 W
Design
Product design	Digital signage flat panel
Product colour	Black
Placement supported	Outdoor
Orientation	Horizontal/Vertical
Screen shape	Flat
VESA mounting	Yes
Panel mounting interface	600 x 400 mm
Bezel width (side)	1.38 cm
Bezel colour	Black
Performance
Purpose	Retail
On Screen Display (OSD) languages	Arabic, Simplified Chinese, Traditional Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Greek, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Swedish, Turkish
Operating hours (hours/days)	24/7
HDCP version	1.4/2.2
Power
Power consumption (typical)	750 W
Power consumption (off)	0.5 W
Power consumption (max)	790 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Heat dissipation	2559 BTU/h
Computer system
Computer system	Yes
Computer system type	System on Chip (SoC)
Internal memory	16 GB
Operating system installed	WebOS
Operating system version	6.0
Weight & dimensions
Display width	1679.2 mm
Display depth	104 mm
Display height	957.6 mm
Display weight	39.6 kg
Packaging data
Package width	1816 mm
Package depth	285 mm
Package height	1106 mm
Package weight	50 kg
Packaging content
Remote control included	Yes
Cables included	AC, HDMI
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80%
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	5 - 85%
Features
Suitable for outdoor use	Yes
Heat dissipation (max)	2696 BTU/h
Technical details
Introduction year	24
Other features
Manual	Yes
