The ARRANGO AZJ60622 HDMI Signal Amplifier allows you to extend high-definition video and audio signals up to 60 meters using standard CAT5e/6/7 network cables. Designed for home, professional, and commercial environments, it ensures stable 1080p@60Hz transmission with minimal latency, making it ideal for presentations, TV installations, surveillance systems, video conferences, and long-distance connections between media sources and displays.

The device supports EDID copy functionality, enabling precise reading and synchronization with the display’s native settings for optimal compatibility. With support for Dolby True HD, DTS-HD Master Audio, and 36-bit deep color, it guarantees high-quality audiovisual performance. Its plug-and-play installation and metal-cased design ensure durability and stable operation, even during extended use.

This amplifier features an HDMI input/output interface and RJ45 network ports for CAT5e/6/7 cables, offering an efficient and cost-effective alternative to long HDMI cables while maintaining excellent performance.

Specifications:

Model: ZJT-13
Compatibility: CAT5e, CAT6, CAT7 cables up to 60 m
Video resolution: 1080p @ 60 Hz
Audio support: Dolby True HD, DTS-HD Master Audio, DTS/Dolby-AC3/DSD
Deep Color: Up to 36-bit
EDID Function: Automatic EDID copy and synchronization
Transmission speed: 6.75 Gbps
Input: HDMI
Output: HDMI
Network port: RJ45 for CAT5e/6/7
Applications: PCs, laptops, TV boxes, DVD players, projectors, HD TVs
Material: Metal enclosure
Installation: Plug-and-play, hot-plug supported
Maximum distance: Up to 60 meters (194 ft)

Key Features:

• Long-distance transmission: Extend HDMI signal up to 60 meters using CAT5e/6/7 cables




• Full HD quality: Supports 1080p @ 60 Hz with stable signal and low latency




• Advanced audio: Compatible with Dolby True HD and DTS-HD Master Audio




• EDID intelligent management: Ensures accurate color, resolution, and display synchronization




• Robust metal design: Durable and resistant for continuous operation




• Plug-and-play: No drivers required, quick installation




• Cost-effective: Uses inexpensive network cables instead of long HDMI cables

In the Box:

• HDMI Signal Amplifier Transmitter




• HDMI Signal Amplifier Receiver




• User Manual
